SF4831 Excavator Bearing Angular Contact Ball Bearing Travel Final Drive Bearing
1) SF4831 bearingspecialized angular ball bearing are used for the appliexcavatorion of excavator machinery.
2) NTN Excavator bearing has big contact angle(40 degree), so can undertake big axial load .
3) Excavator bearing can carry heavier load capacity than the same size bearings because it has
more balls inside. It is widely used for all imported excavator.
4) High-accuracy, low-noise, long-life and this kink of bearing are widely used in excavator.
| Bearing NO. | SF4831VPX1 bearing |
| Size | 240*310*33.4 mm |
| Weight/KG | 5.2 kg / pc |
| Material | GCR-15 |
| Cage | steel |
| Appliexcavatorion | Machinery project |
| Bearing type | Angular contact ball bearing |
| Bearing NO. | d | D | H | W |
| AC5836 | 289 | 355 | 34 | 4.6 |
| AC5033 | 250 | 330 | 37 | 6 |
| AC463240 | 230 | 320 | 40 | 7.2 |
| AC4629 | 230 | 290 | 27 | 3.2 |
| AC4531 | 225 | 315 | 36 | 5 |
| AC423040 | 210 | 300 | 40 | 5.4 |
| AC4630 | 230 | 300 | 35 | 5.4 |
| AC6037 | 300 | 370 | 33 | 5.8 |
| AC4631 | 230 | 310 | 39 | 5.4 |
| AC523438-1 | 260 | 340 | 38 | 6 |
| BA195-3A | 195 | 280 | 36.5 | 6.2 |
| BA152-2036 | 150 | 203 | 26 | 1.5 |
| BA222-1WSA | 222 | 273 | 26 | 2.3 |
| BA220-6WSA | 220 | 276 | 26 | 2.7 |
| BA240-3WSA | 240 | 310 | 33.5 | 4.5 |
| BA230-7WSA | 230 | 300 | 35 | 5.4 |
| BA180-4WSA | 180 | 250 | 33 | 3.2 |
| BA280-2WSA | 280 | 370 | 40 | 6 |
| BA300-4WSA | 300 | 395 | 50 | 11.5 |
| BA205-1 | 202 | 295 | 40 | 7 |
| BA180-2256 | 180 | 2250 | 21.5 | 1.5 |
| BA184-2251 | 184 | 226 | 21.5 | 1.6 |
| BA290-3A | 290 | 280 | 40 | 9.4 |
| BA250-4A | 250 | 330 | 38 | 6.2 |
| BA246-2A | 246 | 313 | 32 | 4.3 |
| BA289-1 | 289 | 355 | 33 | 4.6 |
| BA210-10 | 300 | 280 | 38 | 5.5 |
| BA300-5 | 300 | 380 | 40 | 9.5 |
| BA230-2 | 230 | 320 | 40 | 5.4 |
| BA260-3 | 260 | 340 | 38 | 7.2 |
| Bearing NO. | d | D | H | W |
| BA260-4 | 260 | 340 | 38 | 7.2 |
| BA-220-1 | 220 | 280 | 28 | 3 |
| BA270-3 | 270 | 350 | 40 | 6.6 |
| BA16519 | 165 | 203 | 19 | 1.5 |
| 120BA16 | 120 | 165 | 22 | 1.1 |
| 260BA355-2 | 260 | 355 | 44 | 6 |
| 180BN19W | 180 | 250 | 33 | 3.5 |
| MC6034 | 600 | 340 | 18 | 3.2 |
| BA168-1 | 168 | 205 | 20 | |
| BA200-7B | 200 | 250 | 24 | 2.1 |
| SF2812PX1 | 140 | 175 | 17.5 | 0.6 |
| SF3227VPX1 | 160 | 200 | 10 | 1.2 |
| SF3607 | 180 | 225 | 24 | 1.2 |
| SF4826VPX1 | 240 | 310 | 33 | 5.1 |
| SF4852VPX1 | 240 | 310 | 33 | 5 |
| SF4820PX1 | 240 | 310 | 34 | 5.2 |
| SF4815VPX1 | 240 | 310 | 34 | 5 |
| SF4831VPX1 | 240 | 310 | 33.4 | 5.2 |
| SF4007VPX1 | 200 | 250 | 24 | 1.7 |
| SF4019VPX1 | 200 | 260 | 30 | 3.5 |
| SF3235VPX1 | 260 | 330 | 35 | 5.2 |
| SF4444VPX1 | 220 | 295 | 32 | 4.5 |
| SF4454VPX1 | 220 | 295 | 33 | 4.8 |
| SF4411VPX1 | 220 | 290 | 32.5 | 5.5 |
| SF6015PX1 | 300 | 372 | 36 | 6 |
| 200BA27V | 200 | 270 | 33 | |
| 210BA29V | 210 | 295 | 35 | |
| 240BA3251 | 240 | 320 | 38 | 5 |
| BD130-1WSA | 130 | 166 | 34 | 1.4 |
Excavator Deep groove ball bearing series :
|
| 6209 excavator deep groove ball bearing 45*85*19 mm 6211 excavator deep groove ball bearing 55*100*21 mm 6220 excavator deep groove ball bearing 100*180*34 mm 6204 excavator deep groove ball bearing 20*47*14 mm |
Excavator spherical roller bearing series :
 | 22218 excavator spherical roller bearing 90*160*40 mm 22220 excavator spherical roller bearing 100*180*46 mm 22222 excavator spherical roller bearing 110*200*53 mm 22319 excavator spherical roller bearing 95*200*67 mm |
Excavator inch size tapered roller bearing series :
 | Excavator inch tapered roller bearing 4T-065 (65*130*37.1 mm) Excavator inch tapered roller bearing R196Z-4 (196.85*241.3*12 mm) Excavator inch tapered roller bearing 593/592 (89.09*152.4*39.688 mm) Excavator inch tapered roller bearing 913840/10 (59.987*146.050*41.275 mm) |
Excavator Slewing bearing series :
 | Excavator slewing bearing 021.25.560 (444*676*106 mm ) Excavator slewing bearing 022.60.4500 (4222*4778*226 mm ) Excavator slewing bearing 023.25.500 (384*616*106 mm) Excavator slewing bearing 024.50.2240 (2025*2455*190 mm ) |
Excavator joint bearing series :
 | Excavator joint bearing GE120ES 120*180*70 mm Excavator joint bearing GE180ES 180*260*105 mm Excavator joint bearing GE200ES 200*290*130 mm Excavator joint bearing GE240ES 240*340*140 mm |
Excavator walking bearing series :
 | Excavator walking bearing BA260-4 260*340*38 mm Excavator walking bearing BA240-3ASA 240*310*33.5 mm Excavator walking bearing SF4411VPX1 290*220*32 mm Excavator walking bearing HS05145 117*145*14 mm |
Appliexcavatorions excavators :
Our range of products:
• Angular Contact Ball Bearing
• Ball Bearing
• Cylindrical Roller Bearing
• Deep Groove Ball Bearing
• Double Row Ball Bearing
• Extra Large Size Ball Bearing
• Linear Bushing
• Miniature Ball Bearing
• Needle Roller Bearing
• Pillow Block
• Precision Ball Bearing
• Radial Ball Bearing
• Roller Bearing
• Self-Aligned Ball Bearing
• Single Row Ball Bearing
• Spherical Roller Bearing
• Super Precision Ball Bearing
• Tapered Roller Bearing
• Thrust Ball Bearing
• Thrust Roller Bearing
• Wider Inner Ring Ball Bearing
• Etc.
Packing : 1. Industrial packing 2. Single box +carton +pallets /case 3. According to customers demand Delivery time : 1. Generally after payment: within 3 days . 2. If need produce , about 30 days Payment A less USD1000 , 100% T/T in advance . 1. More USD1000 , 30% T/T in advance , 70%T/T before shipment
Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory and trader .
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment. If you have another question, pls feel free to contact us .
