Good quality TAPPER ROLLER BEARING 20031070 18.8kg Bearings for automotive transmissions

Brand Name : ZH

Model Number : 32040

Place of Origin : China Guangzhou

MOQ : 1 Piece

Price : factory price

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30000 Set/Sets per Month

Packaging Details : Your requirement

Delivery Time : 2-5 days

Certification : IS09001

Product name : TAPPER ROLLER BEARING

Model : 32040

Quality ANK : P0、P2、P4、p5、p6

Packaging : Your requirement

Quality : 18.8kg

MOQ : 1 Piece

SIZE : 200*310*70

Supply : 30000 Set/Sets per Month

Contact Now

32040 32040W 32040X 32040P0VB 32040RS 32040ZZ 32040J2Q 32040W 32040ECK
32040V6 32040 EJ
P6 P5 P3 P4 P2 Quality LEVEL CHROME STEEL tapered roller bearing

Product introduction
32040 Through Hardened Steel Tapered Roller Bearing is a superior component designed to deliver exceptional performance and durability in various industrial applications. This tapered roller bearing is crafted from through
(Good bearing, low price looking ZH)

hardened steel, providing outstanding strength, toughness, and resistance to wear and fatigue. With a size of 200 mm, this bearing is compatible with shafts of corresponding diameter, offering versatility and adaptability

to different machinery and equipment. Its tapered design enables efficient distribution of radial and axial loads, making it suitable for applications with combined loads or heavy axial loads. The 32040 tapered roller bearing is

engineered with precision to ensure smooth and precise operation. The through hardened steel construction enhances the bearing's ability to handle high loads and withstand demanding working conditions. This bearing's tapered

rollers and raceways are carefully designed to reduce friction, dissipate heat, and minimize wear, resulting in improved efficiency and extended service life. It is commonly used in industries such as automotive,

construction, and industrial equipment. The 32040 bearing is known for its reliable performance
Good quality TAPPER ROLLER BEARING 200*310*70 18.8kg Bearings for automotive transmissions

Abutment dimensions

da	max.222 mm	Diameter of shaft abutment
db	min.215.5 mm	Diameter of shaft abutment
Da	min.273 mm	Diameter of housing abutment
Da	max.296.5 mm	Diameter of housing abutment
Db	min.297 mm	Diameter of housing abutment
Ca	min.11 mm	Minimum width of space required in housing on large side face
Cb	min.17 mm	Minimum width of space required in housing on small side face
ra	max.3 mm	Radius of shaft fillet
rb	max.2.5 mm	Radius of housing fillet

Calculation data

Basic dynamic load rating	C	800 kN
Basic static load rating	C0	1 370 kN
Fatigue load limit	Pu	127 kN
Reference speed		1 400 r/min
Limiting speed		1 900 r/min
Limiting value	e	0.43
Calculation factor	Y	1.4
Calculation factor	Y0	0.8

Dimensions

d	200 mm	Bore diameter
D	310 mm	Outside diameter
T	70 mm	Total width
d1	≈254.78 mm	Shoulder diameter of inner ring
D1	999.99 mm	Diameter of flange
B	70 mm	Width of inner ring
C	53 mm	Width of outer ring
r1,2	min.3 mm	Chamfer dimension of inner ring
r3,4	min.2.5 mm	Chamfer dimension of outer ring
a	66 mm	Distance side face to pressure point

Inner Diameter

: 200 mm

Width

: 70 mm

Outer Diameter

: 310 mm

Material

: Through Hardened Steel

Type of Product

: Tapered Roller Bearing

Model No

: 32040

Precision

: ISO Class 5

Lubrication

: Without Oil Hole

Style

: Cone & Cup

Enclosure Type

: Open

Mix it up. It's better for the machine

NUP2206	NUP206	NUP2208=210	NUP207	NUP207/NUP306	NUP310
NUP2207	6305M	NUP307=110	NUP307	30309D	NUP310
NUP2207	4T-30307	NUP207=120	NUP307	30312D	NUP308
NUP2209	HMK3525+IR	NUP2206=130	NUP308	30312D	NUP306
NUP2209	NUP307	NUP2207=140	NUP2211	30312D	NUP307
NUP2209	NUP306	NUP2209=160	NUP2208	30312D	NUP205E
NUP2212	30309D	NUP309=180	NUP309	6008	NUP206E
NUP2212	30210	NUP309=180	NUP309	T7FC065	15578
NUP2211	30210	30312D=155	NUP308	30312D	11749/11710
T7FC055=300	30311D	30312D=155	NUP309	30312	32207
NUP308=140	30311D	30314D=250	NIP2310	30314D	NUP207
30309D=110	T7FC055	NUP2212=220	NUP309	6213	32205
6305	T7FC055	NUP2211=250	NUP2310	NUP208E

Welcome to the product details

Good quality TAPPER ROLLER BEARING 200*310*70 18.8kg Bearings for automotive transmissions
